Orion + LEDSON LED Auxiliary Light 100W Yellow/White Position Light

Description

When futuristic design meets raw power... Ledson Orion +

With its futuristic design, it's hard not to get caught up in the look of the Ledson Orion+... We know how important it is with an auxiliary light that not only exceeds expectations, but is also beautiful to look at. Do you want to have something that turns you into an eye-catcher? Something that increases your vehicle's status in the automotive world? But does it also dutifully ward off the darkness at the end of the night and make your driving much safer?

Of course, we ensure that an auxiliary light that has tomorrow's design also has large amounts of light! 8,500 true lumens and 1 lux brightness at 450 meters and 0.25 lux brightness at 850 meters (by auxiliary light) gives you forward visibility on the road you didn't have before!

In addition to its beautiful design, the auxiliary light is also equipped with a stylish position light that can be adjusted between xenon white and amber: you choose which one you want. If you get tired of one color over time, just switch to the other. Orion+ has a range of E ECE R112/R10/R7 markings, 8,500 true lumens, 6,000K light temperature for a modern look, ETM, EMC, side reflective optical system and more... with great performance, Orion+ leaves you with this must-have feeling!

Thanks to its size and design, the Ledson Orion + fits very well mounted on all types of vehicles.

Steering beam light image

Steering beam reflectors are all computer generated and manufactured to provide a light image similar to the combination, but more consistent and within the limits of what is legal. It imitates and enhances the existing image of the car's headlight and light.

Vehicle mounting

DT Relay: We strongly recommend using our DT relay with original connection to connect the LED bar to the vehicle. You can then choose between controlling the bar with a button or turning it on with the main light (the bar automatically turns on and off when the main light is turned on and off, as most people prefer). There is also a fuse between the external light and the battery to prevent possible damage to the battery and other equipment. Detailed installation instructions are included with the DT relay.
Mounting on the vehicle: It can be mounted directly on the vehicle (drill in a suitable location) or in a slightly smoother and more stylish way using a license plate holder.
TIP: See also our quick relay connector with ready-made connectors, without damaging the car's original cabling (no need for a power thief). Quick and easy installation!

Specifications:

With position light, yellow-orange or xenon white (use whatever color you want)
Steering beam light that mimics and reinforces normal vehicle light
E-marked E9 (Ref. 37.5), ECE R112/R10/R7 (white position light)
Range: 850 m (0.25 lux), 425 m (1 lux)
EMC protected (does not interrupt the radio)
10000 lumen (gross), 8500 lumen (effective)
Cool white light (6000K)
ETM (Electronic Thermal Management) - adjusts diode strength depending on how hot they are for optimal life
Side reflective optical system
Pressure relief membrane
Aluminum Alloy Heat Sink
Adjustable stainless steel stand
Lexan polycarbonate front cover
24 month warranty

Technical Data:

100W (4 x 25W LED)
IP68/IP69K (water/dustproof)
DT connector / DT adapter 2-4 pins supplied with the product
Voltage 9-36V
Load 6.8 A at 12 V and 3.4 A at 24 V

Measurement and weight:

Width: 247 mm
Height: 141 mm (176 mm incl assembly)
Depth: 92 mm
Weight: 1.82 kg

Provided:

Ledson Orion + LED auxiliary light 8 "
Bracket, tabs and screws to secure the light
DT connector (4 poles), don't forget to buy together DT-reläkablage
Installation Instructions

Cable installation (detailed installation instructions included):

Red: Clear (+)
Black: light/position light (- ground)
White: position light (+)
NOTE: The DT connector must not be cut as it involves an increased risk of moisture damage and the warranty then expires.
